Ulottuma: 5.80 - 7.50 m
Nostokyky: 230 kg
Työskentelykorkeus: 14.80 m
Even more technology, versatility of use and innovation of machinery in the JT-LINE series. Almac introduces the new crawler telescopic boom lift JIBBI 1450 EVO, equipped with a JIB that reaches a working height of 14.8 m.
This self-propelled boom lift guarantees simplicity of use and movement thanks to its compact size, allowing use in tight spaces.
To meet market demands and facilitate the various activities performed by end users in a range of applications, Almac has equipped the JIBBI 1450 EVO with the most advanced technology, while maintaining the high performance characteristics typical of the company’s machinery. The self-propelled boom lift is distinguished by its 7.5 m front outreach (with 80kg load), 6.8 m outreach (with 140 kg load) and 5.8 m outreach (with 230 kg load). The variable track undercarriage offers different track widths, specifically 1.35 m, 1.90 m, 2.10 m and 2.45 m.
The JIBBI 1450 can be assembled with a basket measuring 1.4 x 0.7 m. The basket has a rotation angle of +/- 70° and a maximum capacity of 230 kg (2 operators).
Worthy of a special mention is the AUTEC cable console, allowing the machine to be driven with a single joystick.
Similarly to the previous versions in the range, the JIBBI 1450 EVO offers the following advantages:
Dynamic and Proactive automatic levelling, which offers the possibility to work on uneven ground and/or steep slopes, guaranteeing total functionality up to a slope of 15° longitudinally and 15° laterally.
DWP – Dynamic Working Performance, for dynamic control of the machine’s performance characteristics based on different working parameters.
Moreover, operator safety is ensured by the Ultrasonic anti-collision system, which protects operators against sudden and accidental impact in the basket.
Extras for all needs: optionals available for the machine
Almac offers its clients different types of customisations suited to various machine applications, including:
Radio remote control
Non-marking crawlers
Electric pump 220V-2.2kW
Winch kit 200 kg
Lubricant kit for Arctic climate
| Max working height | 14,80 m |
| Max height basket floor | 12,80 m |
| Max outreach (load 80 kg) | 7,50 m |
| Max outreach (load 140 kg) | 6,80 m |
| Max outreach (load 230 kg) | 5,80 m |
| Rotation angle | +/- 110° |
| Basket size | 1,40 x 0,70 m |
| Basket rotation angle | +/- 70° |
| Max basket capacity | 230 kg |
| Length in stowed position (with detached basket) | 4,76 (4,05) m |
| Min width in stowed position | 1,35 m |
| Medium working width | 1,90 m |
| Max working width | 2,45 m |
| Min height in stowed position | 1,99 m |
| Longitudinal leveling | +/- 15° |
| Lateral leveling | +/- 15° |
| Max gradeability | 25° |
| Max side greadeability | 25° |
| Drive speed (fast) | 2,50 km/h |
| Security speed | 0,40 km/h |
| Weights | |
|---|---|
| Traffic load | 2,70 kN/m2 |
| Total weight | 2890 kg |
| Power | |
| Engine | 3TNM68 – AS Yanmar engine (diesel) 14 kW – 19.2 Hp |
